RapidO2 Gas Detector A Trustworthy Alternative to Alphasense for Electrochemical Two-Electrode Detection

RapidO2 Gas Detector A Trustworthy Alternative to Alphasense for Electrochemical Two-Electrode Detection

Electrochemical 2 Electrode Gas Detector

RapidO2 Gas Detector

Alphasense Gas Detector

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

CE

Model Number:

KQT-O2

Contact Us
Request A Quote
Product Details
Output Signal:
100±20 μA In Air
Load Resistance:
100Ω
Temperature Range:
-30℃ - 50℃
Detection Principle:
Electrochemical Two-electrode
Detection Range:
0 - 25%VOL
Maximum Load Concentration:
30%VOL
Highlight:

Electrochemical 2 Electrode Gas Detector

,

RapidO2 Gas Detector

,

Alphasense Gas Detector

Payment & Shipping Terms
Minimum Order Quantity
1PCS
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description

RapidO2 Gas Detector - A Reliable Alternative to Alphasense

1.Overview

The RapidO2 Gas Detector by KACISE is a cutting-edge solution for real-time oxygen monitoring, designed as a reliable alternative to Alphasense. Featuring fast response times (T90 < 20s) and quick return-to-zero functionality, it is ideal for medical, industrial, and environmental applications. With a detection range of 0-25% VOL and high sensitivity, the RapidO2 ensures accurate and stable performance. KACISE’s innovative engineering ensures low power consumption, long-term stability, and excellent repeatability, making this detector a trusted choice for ensuring safety and air quality in diverse settings.

2. Application Fields

1.Oxygen alarms in the mining field

2.Medical oxygen generators

3.Air quality detection instruments

4.Air purification equipment in underground parking lots and commercial areas

5.Air quality detection in vehicles, as well as the fresh air systems of in-vehicle purification equipment

3. Product Features

1. High precision and long service life

2. Fast response speed and quick return to zero

3. Low power consumption and high sensitivity

4. Wide linear range

5. Strong anti-interference ability

6. Excellent repeatability and stability

4. Technical Parameters

Project Parameter
Model KQT-O₂
Detection Principle Electrochemical two-electrode
Detected Gas O₂
Detection Range 0 - 25%VOL
Maximum Load Concentration 30%VOL
Output Signal 100±20 μA in air
Zero-point Drift 0.6%VOL
Resolution 0.1%VOL
Response Time T90 < 20s
Bias Voltage 0
Load Resistance 100Ω
Temperature Range -30℃ - 50℃
Humidity Range 15% RH to 90% RH (no condensation)
Repeatability < ±2% output signal
Long-term Stability < 2% signal / month
Linearity Linear, regression coefficient R² = 0.999
Working Pressure 90 to 110 kPa
Shelf Life 12 months after delivery
Service Life 2 years
