Name: High and Low Limit Alarm Values 50mg/m3 KAN130 Industrial Dust Concentration Measuring Instrument
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KAN130
Price: 72.00 USD
Availability: InStock

Home > products > Gas Detector Sensor >

High and Low Limit Alarm Values 50mg/m3 KAN130 Industrial Dust Concentration Measuring Instrument

KAN130 Dust Concentration Measuring Instrument

Industrial Dust Concentration Measuring Instrument

50mg/m3 Dust Concentration Measuring Instrument

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KAN130

Request A Quote

Product Details

Detection Principle And Type:

Photoelectric Induction

Detection Range:

(10 - 1000) Mg/m³ (Other Ranges Can Be Customized)

Detection Type:

All Kinds Of Dust, PM>10

Sampling Method And Electrical Interface:

Diffusion Type G3/4" Thread (internal)

High And Low Limit Alarm Values:

50mg/m³ (Factory - Set Value)

Operating Voltage And Power Consumption:

DC24V±6V, ≤3W (DC 24 V)

Highlight:

KAN130 Dust Concentration Measuring Instrument

Industrial Dust Concentration Measuring Instrument

50mg/m3 Dust Concentration Measuring Instrument

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KTG113-W Trace Oxygen Analyzer for On-line Analysis of Magnetic Materials 400 ± 10 ml/min Sample Gas Flow Rate

Get Best Price

The KTG112-C Oxygen Analyzer Is Used For On-line Analysis Of Oxygen Content

Get Best Price

KTG114-C Flue Oxygen Analyzer Precise and Fast Oxygen Content Detection for Optimal Furnace Operation

Get Best Price

KTG114-W Explosion Proof Oxygen Analyzer

Get Best Price

86--17719566736

Contact Now

Product Description

KAN130 Industrial Dust Concentration Measuring Instrument

Product Introduction

KAN130 can directly read the concentration of dust particles in the air. It detects dust information by using the principle of light refraction. The sensing probe of the measuring instrument is designed with an open - airflow and optical - path - shielded method to prevent the detection element from being contaminated by dust. It can be used in conjunction with monitoring systems or other controllers, and is suitable for continuous monitoring of dust concentration in various dust - generating workplaces. It has strong expandability, can be powered by solar panels, and can send relevant data information to the computer - port monitoring system via wireless communication. High and Low Limit Alarm Values 50mg/m3 KAN130 Industrial Dust Concentration Measuring Instrument 0

Product Description

Detection Principle and Type	Detection Range	Detection Type	High and Low Limit Alarm Values
Photoelectric induction	(10 - 1000) mg/m³ (Other ranges can be customized)	All kinds of dust, PM>10	50mg/m³ (Factory - set value) 100mg/m³ (Factory - set value)
Sampling Method and Electrical Interface	Operating Voltage and Power Consumption	Operation Method and Communication Distance	Specification
Diffusion type G3/4" thread (internal)	DC24V±6V, ≤3W (DC 24 V)	Infrared remote control distance < 8 meters ≤1000m (wired) ≤3500m (wireless, unobstructed)	Cast aluminum, ≤1.5Kg, 280×166×90
Explosion - proof Mark and Protection Level	Operating Temperature and Humidity	Communication Method	Output Method
Ex ib IIB T4 Gb: Ex ibD 21 T130°C IP66	-10°C - +40°C, ≤85%RH	ABUS (branch line)/RS485 (branch line) (Optional communication methods below) LORA wireless communication	4 - 20mA output, one - way powered GND output (OP) and one set of passive output, and the output following state can be set through adjustment
