Name: KAN151 Temperature and Humidity Transmitter
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KAN151
Price: 72.00 USD
Availability: InStock

Home > products > Gas Detector Sensor >

KAN151 Temperature and Humidity Transmitter

Humidity Transmitter

KAN151 Temperature Transmitter

KAN151 Humidity Transmitter

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KAN151

Request A Quote

Product Details

Temperature Measurement Range And Accuracy:

(-40 - 85)°C, ±0.5°C

Humidity Measurement Range And Accuracy:

(0 - 100)%RH, ±3%RH

Specification:

ABS Plastic, ≤150g, 108×95×45

Temperature Resolution And Humidity Resolution:

0.1°C, 0.1%RH

Operating Voltage And Power Consumption:

DC24V±6V, ≤1.5W

Detection Range:

10 - 20m² Per Unit

Highlight:

Humidity Transmitter

KAN151 Temperature Transmitter

KAN151 Humidity Transmitter

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KTG113-W Trace Oxygen Analyzer for On-line Analysis of Magnetic Materials 400 ± 10 ml/min Sample Gas Flow Rate

Get Best Price

The KTG112-C Oxygen Analyzer Is Used For On-line Analysis Of Oxygen Content

Get Best Price

KTG114-C Flue Oxygen Analyzer Precise and Fast Oxygen Content Detection for Optimal Furnace Operation

Get Best Price

KTG114-W Explosion Proof Oxygen Analyzer

Get Best Price

86--17719566736

Contact Now

Product Description

KAN151 Temperature and Humidity Transmitter

Product Introduction

The transmitter comes with one switch - quantity output, which can be set to output upon alarm (customization required). It is a non - explosion - proof transmitter. The transmitter communicates with the controller via the ABUS method and can be used simultaneously with our company's gas detectors and other products. The power supply and bus parts of the transmitter are both designed with a non - polar connection, and the bus is equipped with an anti - interference and anti - static protection circuit design to ensure the stable operation of the transmitter.

KAN151 Temperature and Humidity Transmitter 0

Product Description

Temperature Measurement Range and Accuracy	Humidity Measurement Range and Accuracy	Communication Method and Distance	Specification
(-40 - 85)°C, ±0.5°C	(0 - 100)%RH, ±3%RH	TBUS two - wire bus, ABUS four - wire bus communication, ≤1000m (1.5mm²)	ABS plastic, ≤150g, 108×95×45
Temperature Resolution and Humidity Resolution	Operating Voltage and Power Consumption	Output Capacity	Detection Range
0.1°C, 0.1%RH	DC24V±6V, ≤1.5W	30V, 2A (maximum contact current)	10 - 20m² per unit
Electrical Interface	Response Time	Output Method
M4 compression screw	<30S (T90)	One group of passive switch - quantity outputs (by default, this function is not available; please contact the manufacturer for customization if needed)
