Place of Origin:
China (Mainland)
Brand Name:
KACISE
Model Number:
KLD-2602
Introduction
Radar Level Gauge is a liquid (material) level recording instrument in the measurement.
The microwave pulse is sent by the antenna,and then is reflected by the material surface , then is received by the radar systems.
Then is sent to the electronic circuit, the microprocessor can identify the microwave pulse echo regenerate the material or the surface of the liquid.
The correct signal is done by intelligent software, up to millimeter accuracy, nonapplicable harsh environments.
What's the Specification Our Radar Level Sensor?
1. Small antenna size, easy to install; Non-contact radar, no wear, no pollution.
2. Almost no corrosion, bubble effect; almost not affected by water vapor in the atmosphere, the temperature and pressure changes.
3. Serious dust environment on the high level meter work has little effect.
4. A shorter wavelength, the reflection of solid surface inclination is better.
5. Beam angle is small, the energy is concentrated, can enhance the ability of echo and to avoid interference.
6. The measuring range is smaller, for a measurement will yield good results.
7. High signal-to-noise ratio, the level fluctuation state can obtain better performance.
8. High frequency, measurement of solid and low dielectric constant of the best choice.
Parameters
|
KLD2602 |
|
|
|
Application:Anti-high temperature, Anti-high pressure Liquid, Mildly corrosive liquid Measuring Range:30 meters Process Connection: Thread, Flange Medium Temperature: -40℃ ~ 250℃ Process Pressure: -0.1 ~ 4.0 MPa Accuracy: ± 3mm Protection Grade: IP67 Frequency Range: 26GHz Explosion-proof Grade:Exia ⅡC T6 Ga/ Exd ia IIC T6 Gb Signal Output:4~ 20mA/HART (Two-wire / Four) RS485/ Modbus
|
Application of radar level sensor
success cases for radar level sensor
KLD series 26G High Frequency Radar Level Meter Other Series
|
KLD2601 |
|
|
|
Application: All kinds of corrosive liquid Measuring Range:10 meters Process Connection: Thread, Flange Medium Temperature: -40℃ ~ 130℃ Process Pressure: -0.1~0.3 MPa Accuracy: ± 5mm Protection Grade: IP67 Frequency Range: 26GHz Signal Output:4~ 20mA/HART (Two-wire / Four) RS485/ Modbus Explosion-proof Grade:Exia ⅡC T6 Ga/ Exd ia IIC T6 Gb
|
|
KLD2603 |
|
|
|
Application:Solid material, Strong dust Easy to crystallize, condensation occasion Measuring Range:70 meters Process Connection: Universal Flange Medium Temperature: -40℃ ~ 250℃ Process Pressure: -0.1 ~ 0.1 MPa Accuracy: ± 15mm Protection Grade: IP67 Frequency Range: 26GHz Signal Output:4~ 20mA/HART (Two-wire / Four) RS485/ Modbus Explosion-proof Grade:Exia ⅡC T6 Ga/ Exd ia IIC T6 Gb
|
|
KLD2604 |
|
|
|
Application:Solid material, Strong dust, easy to crystallize, condensation occasion Measuring Range:80 meters Process Connection: Universal Flange Medium Temperature: -40℃ ~ 250℃ Process Pressure: -0.1 ~ 0.1 MPa Accuracy: ± 15mm Protection Grade: IP67 Frequency Range: 26GHz Signal Output:4~ 20mA/HART (Two-wire / Four) RS485/ Modbus Explosion-proof Grade:Exia ⅡC T6 Ga/ Exd ia IIC T6 Gb
|
|
KLD2605 |
|
|
|
Application:Solid material, Strong dust, easy to crystallize, condensation occasion Measuring Range:80 meters Process Connection: Universal Flange Medium Temperature: -40℃ ~ 250℃ Process Pressure: -0.1 ~ 0.1 MPa Accuracy: ± 15mm Protection Grade: IP67 Frequency Range: 26GHz Signal Output:4~ 20mA/HART (Two-wire / Four) RS485/ Modbus Explosion-proof Grade:Exia ⅡC T6 Ga/ Exd ia IIC T6 Gb
|
|
KLD2606 |
|
|
|
Application:Solid particles, Powder Corrosive medium container Measuring Range:20 meters Process Connection:Liquid 30m/Solid 20m/powder 15m Medium Temperature:-40℃ ~ 250℃ Process Pressure: -0.1 ~ 4.0MPa (Flat Flange) -0.1 ~ 0.1MPa (Universal Flange)
Accuracy:± 10mm Protection Grade:IP67 Frequency Range:26GHz Power Supply: Two-wire (DC24V) / Four-wire (DC24V/AC220V) Signal Output:4... 20mA/HART (Two-wire / Four) RS485/ Modbus Explosion-proof Grade:Exia ⅡC T6 Ga/ Exd ia IIC T6 Gb
|
