High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output

High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output

  • High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output
  • High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output
  • High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output
  • High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output
High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output
Product Details:
Place of Origin: CHINA
Brand Name: KACISE
Certification: CE
Model Number: KUM-C
Payment & Shipping Terms:
Minimum Order Quantity: 0-100
Price: USD50-120/pcs
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 10000pcs/month
Contact Now
Detailed Product Description
Range: 5m, 10m Accuracy: 0.5%, 1%
Medium: Liquid, Solid
High Light:

ultrasonic fluid level sensor

,

ultrasonic level transmitter

KUM-C Digital Intellient High Accuracy Ultrasonic Level Meter Non-Contact Level Sensor



KUM-C ultrasonic level meter is a non-contact and cost-effective level meter with high reliability, high accuracy and easy installation. It does not have to contact the medium and can meet the measuring requirements of most applications.



1. Technical Features:



  • Non-contact, can be used in various applications;
  • High accuracy: 0.5%, 1%
  • Various types of probes are available to meet the requirements of various applications.



2. Structure:



High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output 0



















































3. Technical Specifications:



Specs Value
Pressure Voltage 5m, 10m
Accuracy 0.5%, 1.0%
Display LCD
Ambient Temperature Display instrument-20～+60℃
transducer-20～+80℃
Medium liquid and solid
Analog Output 4-20mA
Digital Output RS485, RS232 (both are optional)
Power Supply 24Vdc
Protection Grade Display instrument IP65,transducer IP68
Probe Type PVDF, aluminum alloy, ABS, stainless steel 316L, teflon, titanium alloy





4. Model Selection:



KUM-C
  Measurement Range
A 5 meter
B 10 meter
  Output Signal
A 4-20mA
  Accuracy
0.5 0.5%
1.0 1%
  Power Supply
A 24Vdc
B 11~30Vdc
  Probe Type
A PVDF
B Aluminum alloy
C ABS
D Stainless steel 316L
E Teflon
F Titanium alloy



5. Applications and Installations:



  • Distance measurement
  • Depth measurement



High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output 1

High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output 2

High Accuracy Ultrasonic Fluid Level Meter KUM-C Non - Contact 4-20mA Output 3
