Name: Digital Integrated Ultrasonic Level Meter 24V DC Power Supply High Accuracy
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUM-A
Price: 1,000.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

Digital Integrated Ultrasonic Level Meter 24V DC Power Supply High Accuracy

ultrasonic level transmitter

ultrasonic liquid level sensor

Place of Origin:

China

Brand Name:

kacise

Certification:

ce，iso9000

Model Number:

KUM-A

Document:

KUM intelligent ultrasonic ....2.pdf

Request A Quote

Product Details

RANGE:

5m, 10m, 15m, 20m, 30m, 40m, 50m, 60m

ACCURANCY:

0.5%, 1%

POWER SUPPLY:

24V DC

OUT PUT:

4-20mA

CONECT SIZE:

M78*2

MATERIAL:

PVDF, Aluminum Alloy, ABS, Stainless Steel 316L, Teflon, Titanium Alloy

BLIND ZONE:

DEPENDS RANGE

OPERATING TEMPARATURE:

Display Instrument-20～+60℃ Transducer-20～+80℃

Highlight:

ultrasonic level transmitter

ultrasonic liquid level sensor

Payment & Shipping Terms

Minimum Order Quantity

0-100

Price

Negotiable

Packaging Details

carton or customers requests available

Delivery Time

10 working days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100pieces/week

4-20ma Output Laser Transmitter Pyrometer Non Contact Infrared Temperature Sensor With Laser Targeting

Get Best Price

KWG200 Gas Monitor,DC3.6V lithium battery，detect methane

Get Best Price

LSBM-100 Surveying and Mapping Laser Ranging Module

Get Best Price

Externally-mounted Liquid Level Gauge Digital Display For Monitoring Industrial Spherical Tanks Liquid Level

Get Best Price

86--17719566736

Contact Now

Product Description

Digital Integrated Ultrasonic Level Meter Used in Liquid level material monitoring and measurement field

KUM-A ultrasonic level meter is a non-contact and cost-effective level meter with high reliability, high accuracy and easy installation. It does not have to contact the medium and can meet the measuring requirements of most applications.

Technical Features:

Non-contact, can be used in various applications;
Various types of probes are available to meet the requirements of various applications.
High accuracy: 0.5%, 1%
English LED Display

Structure:

Digital Ultrasonic Water Meter High Performation Non - Contact High Accuracy

Technical Specifications:

Specs	Value
Range	5m, 10m, 15m, 20m, 30m, 40m, 50m, 60m
Accuracy	0.5%, 1.0%
Display	LCD
Ambient Temperature	Display instrument-20～+60℃ transducer-20～+80℃
Medium	liquid and solid
Analog Output	4-20mA
Digital Output	RS485, RS232 (both are optional)
Power Supply	24Vdc
Protection Grade	Display instrument IP65,transducer IP68
Probe Type	PVDF, aluminum alloy, ABS, stainless steel 316L, teflon, titanium alloy

Model Selection:

KUM-A
	Measurement Range
	A	5m
	B	10m
	C	15m
	D	20m
	E	30m
	F	40m
	G	50m
	H	60m
		Output Signal
		A	4-20mA
			Accuracy
			0.5	0.5%
			1.0	1%
				Power Supply
				A	24Vdc
				B	11~30Vdc
					Probe Type
					A	PVDF
					B	Aluminum alloy
					C	ABS
					D	Stainless steel 316L
					E	Teflon
					F	Titanium alloy

Applications and Installations:

Distance measurement
Depth measurement

Digital Ultrasonic Water Meter High Performation Non - Contact High Accuracy
