KUS650 Wireless Ultrasonic Level Sensor PVDF Real Time Low Power Consumption

Product Details:

Place of Origin:	China
Brand Name:	Kacise
Model Number:	KUS650

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	carton
Delivery Time:	5-8 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	100+

Contact Now

Detailed Product Description

Range:	20-4000mm（customizable）	Accuracy:	±0.15%FS/ 0.15℃
Temperature Compensation:	-10℃～70℃	Ambient Temperature:	-25～+85℃
Storage Temperature:	-40～+85℃	IP Grade:	IP65
Connector:	1NPT，stainless Steel，length 20mm（customizable）
High Light:	Wireless Ultrasonic Level Sensor , PVDF Real Time Ultrasonic Level Sensor , Ultrasonic Fluid Level Meter

KUS650 Wireless Ultrasonic Level Sensor PVDF Real-time Low power consumption

Introduction

KUS650 series intelligent wireless digital wireless liquid level/level sensor is an intelligent digital display product with high precision and high stability introduced by our company. Suitable for real-time measurement and display of liquid level/material level. This product adopts special wide temperature liquid crystal display, high stability sensor, and is carefully manufactured through precise digital temperature compensation and nonlinear correction technology to ensure the high precision and high stability of liquid level/level measurement. The built-in wireless module uses the network to provide users with wireless long-distance and low-power data transmission, and sends all the status data of the sensor to the cloud background management server in real time to realize alarm linkage and data statistical analysis with the smart cloud platform.

Feature

⚫ Power: Two DC3.6V primary lithium sub-battery

⚫ Wireless transmit power: <23 dBm

⚫ Receive sensitivity: <-135 dBm

⚫ Theoretical bandwidth: 200Kbs

⚫ Support wireless transmission of alarm status to server, configurable server address and port

⚫ Using precise digital temperature compensation and nonlinear correction technology, wide temperature range and full scale precision compensation;

⚫ Multiple data type indication (percentage, output current display);

⚫ Special wide temperature LCD display (-30℃～80℃);

⚫ Provide a variety of power supply methods at the same time;

⚫ Vertical installation or axial installation, providing a variety of liquid level/level interfaces and interface materials;

⚫ LCD with parameterization and three setting buttons.

⚫ According to user needs and site conditions, the collection frequency and time interval can be set.

⚫ Battery power monitoring, when the power is insufficient, the meter screen will flash and report to the centralized management platform at the same time.

⚫ Water pressure/water level alarm threshold can be set and modified according to actual needs.

⚫ Water pressure/water level alarm threshold automatically alarms.

Application

⚫ Fire water system

⚫ Urban water supply

⚫ Sewage treatment

⚫ Long distance heating

⚫ Food industry

⚫ Chemical, Energy

Parameter

Range	20-4000mm(customizable)
Accuracy	±0.15%FS/ 0.15℃
Temperature Compensation	-10℃～70℃
Vibration Effects	< ± 0.05％/g, all directions 500Hz (IEC 68 -2-64)
Ambient Temperature	-25～+85℃
Storage Temperature	-40～+85℃
IP Grade	IP65
Electromagnetic Compatibility	EN 61326/A2 Appendix A (2001 )
Display	SFTN LCD, white backlight, 5-digit display
limit value	Free setting
Parameter Setting	Using 3 buttons
Unit	mm, default is m
Weight	Around 1.35kg
Connector	1NPT,stainless steel,length 20mm(customizable)
Electrical Connections	Watertight connector, air vent cable entry according to EN 175301- 803A
Measurement Period	≤ 100ms

Tips: For special requirements, please contact our company and indicate it in the order. Precautions: 1. If you need to calibrate the instrument, please contact our company. Non-professionals are not allowed to calibrate the instrument. 2. When calibrating the watch, please turn on the watch first, and then calibrate after 1 hour of constant temperature.
