Name: High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXPS400 series
Price: 115.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy

Customized Fuel Tank Level Transmitter

1.0% Accuracy Fuel Tank Level Sensor

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

GXPS400 series

Request A Quote

High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy

Product Details

Accuracy:

0.25%, 0.5%, 1.0%

Temperature:

Customized Available

Transmitter Name:

Fuel Tank Level Sensor

Port:

Shanghai Or Other

Highlight:

Customized Fuel Tank Level Transmitter

1.0% Accuracy Fuel Tank Level Sensor

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Price

$50.00 - $180.00/pieces

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Supply Ability

1000 Piece/Pieces per Week negotiable

KDI Series Display Controller Supporting Multi - Machine Communication

Get Best Price

Video

KDI Series Display Controller with Open Internal Parameter Setting Interface High Accuracy and 0.1 Resolution

Get Best Price

Video

Accurate KDI Series Measurement Display Controller with Multiple Index Input Switching and Temperature Compensation

Get Best Price

Video

KDI Series Light Column Display Controller With Digital And Analog Measurement

Get Best Price

86--17719566736

Contact Now

Product Description

High accuracy fuel tank level transmitter

1. Specification:

Spec.	Numerical value			Remark
Pressure range	0~1……500mH2O			1mH2O≈9.81kPa
Overload pressure	1.5times Rated pressure
fracture pressure	3 times rated pressure
Accuracy	0.25%F.S, 0.5%F.S, 1.0%F.S
Accuracy	0.25%F.S, 0.5%F.S, 1.0%F.S
Stability	Typical value: 0.1%F.S Max.: 0.2% F.S/year
Operating Temperature	-40°C~85°C or -40 °C ~125 °C
compensation temperature	-10°C~70°C
medium compatibility	All Caustic Medium Compatible with 1Cr18Ni9Ti and 316L
electrical properties	2 line	3 line
Output signal	4~20mA	0~5V	0~10V
Power supplies	10~30Vdc	80~30Vdc/ac	11~30Vdc/ac	Vdc/ac
load resistance	(U-10)/0.02( Ω )	more than 100k Ω
insulation	more than 100M Ω @50V
Electrical Connections	waterproof fixed cable + Two rectangle circle+Sealing Rings+seal gum+ Pure glue protection grade : IP68
pressure interface	G1/4,input type
response time	10ms
Electric strength	500Vac@1 second
Graduate Certificate Programs	certificate of explosion-proof, CE
electromagnetic compatibility	electromagnetic radiation EN50081-1/-2, electromagnetic susceptibilty: EN50082-2
lightning protection	air conduction resistance 8000V,case, cable conduction

2. Feature

1). Diffused-Silicon oil filled core

2). All kinds of structure to satisfy different users

3). Easy to use with submersible measuring

4). Multiple pressure range and signal output

5). Non-polar 2 wire system current output

6). Can be used in lightning protection products

7). Reinforcing rib of liquid cable

8). Intrinsically safe explosion proof, Isolation explosion proof, CE

3. Application

1). Deep well level measuring

2). Hydrologic measurement for river, lake, sea

3). Sewage treatment

4). Cloudy level measuring

5). Fluid reservoir level measuring

6). Water-saving irrigation

7). Circulating liquid consumption monitoring

8). Diversion works

4. Electric connection & structure

Production Flow

High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy 1

Cases

High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy 2

Packaging & Shipping

High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy 3

Certificates

High Accuracy Fuel Tank Level Transmitter 0.25% 0.5% 1.0% Accuracy 4
