Name: low cost high quality low differential pressure sensor,Protection IP65
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXSENSORS-PS540
Price: 61.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

low cost high quality low differential pressure sensor,Protection IP65

Place of Origin:

Shaanxi, China

Brand Name:

GXSENSOR support OEM

Certification:

certificate of explosion-proof, CE

Model Number:

GXSENSORS-PS540

Request A Quote

low cost high quality low differential pressure sensor,Protection IP65

Product Details

Usage:

PRESSURE SENSOR

Theory:

Resistance Sensor

Output:

Analog SENSOR

Certificate::

Warranty:

12 Months Exchange

Type:

Low Differential Pressure Sensor

Port:

Shanghai Or Other

Medium Temperature:

-10~100°C

Protection:

IP65

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Price

$55.00 - $68.00/pieces

Packaging Details

1pc/box, many boxes/ carton, some carton/wooden case, or customers requests available

Delivery Time

5-8 work days

Payment Terms

T/T, Western Union, MoneyGram

Supply Ability

10000 Piece/Pieces per Week negotiable

4-20ma Output Laser Transmitter Pyrometer Non Contact Infrared Temperature Sensor With Laser Targeting

Get Best Price

KWG200 Gas Monitor,DC3.6V lithium battery，detect methane

Get Best Price

LSBM-100 Surveying and Mapping Laser Ranging Module

Get Best Price

Externally-mounted Liquid Level Gauge Digital Display For Monitoring Industrial Spherical Tanks Liquid Level

Get Best Price

86--17719566736

Contact Now

Product Description

low cost high quality low differential pressure sensor

Feature

High sensitivity

High accuracy and high stability

Mini outline, easy to install

Application

Boiler

Dust precipitator

Air duct pressure

Differential and negativepressure

Instruction

GXPS540 series low differential pressure sensor Wind Pressure & Differential Pressure Transmitter adopts high-precision, high stability diaphragm and is assembled by stress isolation technics. By strict precision temperature compensation and signal amplification, transfer micro differential pressure, air pressure, flow and other parameters to reliable 4~20mA or 1~5V signal output.

Parameter of 2024 low cost high quality low differential pressure sensor

Measuring range:	0-100Pa~100Kpa; -50KPa~-50Pa-50Pa~50Kpa
Protection:	IP65
Medium Measurement:	Non-corrosive dry gas; weak corrosive and damp gas
Output signal:	4~20mA, 1~5V, 0~5V Optional
Operating voltage:	24VDC
Accuracy:	±0.2% F.S., ±0.5% F.S., ±1% F.S. Optional
Adjustment	Zero and range are adjustable externally
Medium temperature:	-10~100°C
Ambient temperature :	-20~80°C
Electric Interface:	outlet cable
Shell material:	Aluminum alloy

Dimension

low cost high quality low differential pressure sensor,Protection IP65 0

Ordering information

GXPS540						Product Serial
	X (Pa or KPa)					Pressure Range
		0.3				±0.3%FS Accuracy
		0.5				±0.5%FS Accuracy
		1.0				±1%FS Accuracy
			4mA			4~20mA Output
			V0			0~5VDC Output
			V1			1~5VDC Output
			RSV			reserved
				F8		Φ8 tower-type interface
				RSV		reserved
					CX	X meters Cable
					RSV	reserved
GXPS540	1KPa	0.3	4mA	F6	C2	Example
