KUM NEW Ultrasonic sensors level meter

KUM NEW Ultrasonic sensors level meter

  • KUM NEW Ultrasonic sensors level meter
  • KUM NEW Ultrasonic sensors level meter
  • KUM NEW Ultrasonic sensors level meter
KUM NEW Ultrasonic sensors level meter
Product Details:
Place of Origin: Shaanxi, China
Brand Name: Kacise
Model Number: KUM
Payment & Shipping Terms:
Price: $80.00 - $350.00/pieces
Packaging Details: carton or wooden box
Supply Ability: 5000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Transmitter Name: Ultrasonic Sensors Level Meter Power Supply: 24VDC/220VAC
Measuring Range: Max. 60m Accuracy: 0.25%-0.5%F.S
Output Signal: 4-20mA/RS485 / 0-10V / Relay Port: Xi'an Or Other

KUM NEW Ultrasonic sensors level meter





Features of water level sensor

  • Cost effective.
  • Non-Contact measurement.
  • Accuracy can be 0.3% and against all kinds of interference waves.
  • Easy to use spport Modbus protocol (both RTU and ASCII).
  • Eight types algorithm can be choose to adapt to a variety application field.
  • Easy to installation and set,you can calibrate the instrument completely according to our manual.
  • This instrument is a non-contact instrument, so it has low breakdown rate. It provides a variety of installation methods.

Parameters of water level sensor



Function

Integral type

Split type

Range

5m,10m,15m,20m,30m,40m,50m,60m

5m,10m,15m,20m,30m,40m,50m,60m,70m

Accuracy

0.25%-0.5%

0.25%-0.5%

Resolution

3mm or 0.1%(which is bigger)

3mm or 0.1%( which is bigger)

Display

Chinese and English LCD

Chinese and English LCD

Analog output

4wires4~20mA/750Ω load

2wires4~20mA/250Ω load

4~20mA/750Ω load

Relay output

2groups AC 250V/ 8A or DC 30V/ 5A state programmable(optional)

Single channel for two groups, double channels for four groups AC 250V/ 8A or DC 30V/ 5A state programmable(optional)

Power supply

Standard configuration 24VDC

optional 220V AC+15% 50Hz

optional 12VDC or customerized

Standard configuration 220V AC+15% 50Hz

optional 24VDC 120mA

optional 12VDC or customerized

Temperature

Display instrument-20~+60°C,

transducer-20~+80°C

Display instrument -20~+60°C,

transducer-20~+80°C

Communication

RS485,232 communication(Manufacturer agreement)

RS485,232 communication(Manufacturer agreement )

Protection grade

Display instrument IP65,transducer IP68

Display instrument IP65,transducer IP68

Transducer cable

no

Up to 100 m, Standard   configuration 10m

Installation

According to the range and   transducer select

According to the range and   transducer select



 Note: This series of ultrasonic level meter can also customize according to the customer demands: special specifications of transducer such as high voltage, high temperature resistant, minor-caliber, small blind area and so on.



Production Flow

KUM NEW Ultrasonic sensors level meter 0

Cases

KUM NEW Ultrasonic sensors level meter 1

Packaging & Shipping

KUM NEW Ultrasonic sensors level meter 2

Certificates

KUM NEW Ultrasonic sensors level meter 3

Company Information

KUM NEW Ultrasonic sensors level meter 4

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.

We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.



Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.

Our Services



  • Your inquiry will be replied in 24hours.
  • Well-trained and experienced staffs to answer all your enquires in fluent English.
  • OEM&ODM, we can help you to design and your request will be put into product.
  • Distributorship are offered for your unique design and some our current models.
  • Protection of your sales area, ideas of design and all your private information.
  • Discounts are offered based on order quantities.
  • We provide paid repair services for meter damages not arising from manufacturing quality issues or meter damages not within the scope of warranty.
FAQ

1. Q: What information need to be provided to choose the suitable model?

 A: Please provide us: application fieldrange , output signalmedium( liquid type),

         and power supplyso we can choose model and quote for you quickly.

2. Q: Are you a trade company or a manufacturer?

    A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.

        OEM & ODM service are available. Welcome to visit us.

3. Q: What is your MOQ?

    A: To start our cooperation, sample order is acceptable.

4. Q: What is your delivery date?

    A: The delivery date is about 3-15 working days after receipt of payment.

5. Q: What is your payment terms?

    A: We support T/T, PayPal and Trade Assurance.

         For mass production order, it is 30% deposit in advance and 70% balance before shipment.

6. Q: What is Trade Assurance payment method:

    A: It’s a free service which can protect your orders from payment to delivery.

        And we now have USD104,000.00 of caution money to assure your orders.

7. Q: Do you have a warranty?

    A: Yes, we have the warranty of 12 months.
