| Place of Origin: | China |
| Brand Name: | Kacise |
| Model Number: | KUM |
| Price: | $80.00 - $300.00/pieces |
|---|---|
| Packaging Details: | carton or customers requests available |
| Supply Ability: | 10000 Piece/Pieces per Week negotiable |
| Theory: | Ultrasonic Sensor | Type: | Ultrasonic Level Sensor |
|---|---|---|---|
| Output Signal: | 4-20mA/0-5V/0-10V/RS485 | Power Supply: | 24VDC/220VAC |
| Measuring Range: | Max. 60m | Port: | Shanghai Or Other |
Features of water level sensor
Parameters of water level sensor
|
Function |
Integral type |
Split type |
|
Range |
5m,10m,15m,20m,30m,40m,50m,60m |
5m,10m,15m,20m,30m,40m,50m,60m,70m |
|
Accuracy |
0.25%-0.5% |
0.25%-0.5% |
|
Resolution |
3mm or 0.1%(which is bigger) |
3mm or 0.1%( which is bigger) |
|
Display |
Chinese and English LCD |
Chinese and English LCD |
|
Analog output |
4wires4~20mA/750Ω load 2wires4~20mA/250Ω load |
4~20mA/750Ω load |
|
Relay output |
2groups AC 250V/ 8A or DC 30V/ 5A state programmable(optional) |
Single channel for two groups, double channels for four groups AC 250V/ 8A or DC 30V/ 5A state programmable(optional) |
|
Power supply |
Standard configuration 24VDC optional 220V AC+15% 50Hz optional 12VDC or customerized |
Standard configuration 220V AC+15% 50Hz optional 24VDC 120mA optional 12VDC or customerized |
|
Temperature |
Display instrument-20~+60°C, transducer-20~+80°C |
Display instrument -20~+60°C, transducer-20~+80°C |
|
Communication |
RS485,232 communication(Manufacturer agreement) |
RS485,232 communication(Manufacturer agreement ) |
|
Protection grade |
Display instrument IP65,transducer IP68 |
Display instrument IP65,transducer IP68 |
|
Transducer cable |
no |
Up to 100 m, Standard configuration 10m |
|
Installation |
According to the range and transducer select |
According to the range and transducer select |
Note: This series of ultrasonic level meter can also customize according to the customer demands: special specifications of transducer such as high voltage, high temperature resistant, minor-caliber, small blind area and so on.
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
1. Q: What information need to be provided to choose the suitable model?
A: Please provide us: application field, range , output signal, medium( liquid type),
and power supply, so we can choose model and quote for you quickly.
2. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us.
3. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
4. Q: What is your delivery date?
A: The delivery date is about 3-15 working days after receipt of payment.
5. Q: What is your payment terms?
A: We support T/T, PayPal and Trade Assurance.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
6. Q: What is Trade Assurance payment method:
A: It’s a free service which can protect your orders from payment to delivery.
And we now have USD104,000.00 of caution money to assure your orders.
7. Q: Do you have a warranty?
A: Yes, we have the warranty of 12 months.
