Name: Economic high accuracy silicon piezoresistive pressure sensor
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXPS400
Price: 185.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

Economic high accuracy silicon piezoresistive pressure sensor

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

GXPS400

Request A Quote

Economic high accuracy silicon piezoresistive pressure sensor

Product Details

Pressure Range:

0~100mpa

Accuracy:

±0.1%F.S, ±0.25%F.S, ±0.5%F.S

Output Signal:

4~20mA, 1~5V, 0~5V, 0~10V

Power Supply:

10~30Vdc, 6~24Vdc, 11~30Vdc

Certificate:

Intrinsically Safe Mode E, CE

Feature:

Piezoresistive Pressure Sensor

Operating Temperature:

-20~80℃

Medium:

Liquid, Gas

Port:

Shanghai Or Other

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Price

$80.00 - $290.00/sets

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Supply Ability

1000 Piece/Pieces per Week negotiable

KDI Series Display Controller Supporting Multi - Machine Communication

Get Best Price

Video

KDI Series Display Controller with Open Internal Parameter Setting Interface High Accuracy and 0.1 Resolution

Get Best Price

Video

Accurate KDI Series Measurement Display Controller with Multiple Index Input Switching and Temperature Compensation

Get Best Price

Video

KDI Series Light Column Display Controller With Digital And Analog Measurement

Get Best Price

86--17719566736

Contact Now

Product Description

Economic high accuracy silicon piezoresistive pressure sensor

Economic high accuracy silicon piezoresistive pressure sensor 0

Features

Features of silicon pressure sensor

High Accuracy and stability
Φ19 mm standard Dimension
Pressure port can be customized
Wide measurement Range:0~10KPa~100Mpa

Applications

Applications of piezoresistive pressure sensor

Pressure transmitter
Petroleum exploitation
Process control system
Water supply, warm supply of town
Aviation and navigation inspection
Measurement pressure of gas and liquid

Specifications

Specifications of pressure sensor

Parameter
Range		0~10,35,70,100,200,350,700,1000,2000,3500KPa 0~7,10,20,35,60,100MPa
		Typical	Max.	Units
Pressure Non-linearity		±0.15(0-2MPa) ±0.2(3.5MPa-60MPa)	±0.3	%F.S
Repeatability and Hysteresis		0.02	0.05	%F.S
Zero output		0±1	0±2	mV
Span output	≤20KPa	50±10	50±30	mV
	≥35KPa	100±10	100±30	mV
Temp. error-zero	≤20KPa	±1	±2	%F.S
	≥35KPa	±0.5	±1	%F.S
Temp. error-span	≤20KPa	±1	±2	%F.S
	≥35KPa	±0.5	±1	%F.S
Proof pressure		3X rated range or 120MPa,whichever is less		------
Operating Temp. range		-20~80		°C
Compensated Temp. range		0~70, 0~50(range≤20KPa)		°C
Storage Temp. range		-40~125		°C

Note: Above parameter under condition: Supply 1.5mA, temperature 25°C.

Electrical Data

Supply :1.5mADC
Input impedance:3KΩ~6KΩ
Output impedance:2.5KΩ~6KΩ Insulation resistance:≥100MΩ/50VDC
Insulation voltage: 500VAC between the housing and electrical connection will not damage
Medium compatible: liquid, gas compatible with 316L Stainless steel

Dimension

Dimension of silicon piezoresistive pressure sensor


Economic high accuracy silicon piezoresistive pressure sensor 2

Our Services

Our Services

Sensor can be customized by your special request, We can supply technical consulting service for your user.
The quality principle: Quality is the best sales
Payment: We accept T/T, PayPal, Western Union, MoneyGram , Escrow
Shipping:
1. All parts will be shipped out within 1 - 3 working days after confirm the payment
2. DHL / FEDEX / UPS / EMS / TNT / China Post /Aramex
3. We are not responsible for force majeure accidents, delays or other issues, like the shipping service.

After-sales service
We can offer good technical support and good warranty for you after service as professional manufacturer.

Warranty: One year
During the warranty, if the goods after delivery are damaged with error caused only by itself quality problem, the goods can be returned for free repair and maintenance. however, if the goods is damaged with error caused by user’ s man-made and force majeure factor, we will be not responsible for free repair and maintenance.
