Name: RS485 RS232 Ultrasonic Level Meter Long Range Ultrasonic Sensor
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUS/KUM
Price: 185.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

RS485 RS232 Ultrasonic Level Meter Long Range Ultrasonic Sensor

Ultrasonic Fluid Level Meter RS232

RS485 Modbus Fluid Level Meter

Ultrasonic Fluid Level Sensor

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KUS/KUM

Document:

KUS3000 Ultrasonic Level Me....1.pdf

Request A Quote

Product Details

Usage:

Level Sensor

Theory:

Ultrasonic Sensor

Output:

Switch Transducer, Analogue Transducer,digital Transducer

Analog Output:

40-20mA, 0/1-5V, 0/1-10V Optional

Measuer Distance:

Max. 60m

Power Supply:

12-30VDC

Digital Output:

RS485, RS232

Digital Protocol:

Modbus, Sefdefination Protocol Based On Iso Optional

Protection Degree:

IP67

Product Feature:

Long Range Ultrasonic Sensor

Material Housing:

Brass, Nickel-plated

Port:

Shanghai Or Other

Highlight:

Ultrasonic Fluid Level Meter RS232

RS485 Modbus Fluid Level Meter

Ultrasonic Fluid Level Sensor

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Price

$70.00 - $300.00/pieces

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Supply Ability

1000 Piece/Pieces per Week negotiable

Corrosion Resistant Capacitive Level Transmitter With NPN/PNP Output Is Used For Level Monitoring In Laboratory Reactors

Get Best Price

Video

KLD800 Series 80G Radar Level Gauge PTFE Antenna Size Small Blind Spot

Get Best Price

Video

0.1m~3m Capacitive Water Level Sensor High Performance And Wide Range

Get Best Price

1m Liquid Tank Level Sensor IP67 Fluid Level Meter RS485 Output

Get Best Price

86--17719566736

Contact Now

Product Description

RS485 RS232 Ultrasonic Level Meter Long Range Ultrasonic Sensor

Product Overview

Precision ultrasonic level meter with RS485/RS232 communication interfaces designed for industrial liquid level measurement applications. Features long-range detection up to 60m with multiple output options and robust construction.

Key Specifications

Usage	Level Sensor
Measurement Principle	Ultrasonic Technology
Output Options	Switch transducer, Analog transducer, Digital transducer
Analog Output	4-20mA, 0/1-5V, 0/1-10V (selectable)
Maximum Range	60 meters
Power Supply	12-30VDC
Digital Interface	RS485, RS232
Housing Material	Brass, nickel-plated
Protection Rating	IP67

Product Features

High sensitivity ultrasonic measurement technology
Continuous measurement capability with real-time output
Wide operating voltage range (9V-28V) with low power consumption
Multiple output options including analog, RS485, and CAN bus
Operates at multiple frequency bands (40 KHz to 1 MHz)
Modbus and custom protocol support
Robust brass housing with nickel plating

Technical Parameters

KUM Series Models

Model	KUM-A	KUM-B
Type	Integrated	Split
Range	5m-60m	5m-70m
Accuracy	1%	1%
Resolution	3mm or 0.1%	3mm or 0.1%
Power Options	24VDC or 220VAC	220VAC or 24VDC
Protection Grade	LED: IP65, Probe: IP68	LED: IP65, Probe: IP68

M18 Model Specifications

Sensing Range	150-1000 mm
Response Delay	≈10 ms
Operating Voltage	13-30V DC

Manufacturer Information

Xi'an Kacise is ISO 9001-2008 and GJB 9001B-2009 certified manufacturer specializing in pressure, level and flow measurement instruments for over 10 years. Our products are CE certified and meet international standards for intrinsic safety explosion-proof applications.

Our sensors are exported to over 20 countries including America, Spain, Australia, and Chile. We offer OEM/ODM services and maintain strict quality control throughout our production process.

Our Services

24-hour inquiry response
OEM/ODM customization available
Distributorship opportunities
Volume discounts
12-month product warranty
Trade Assurance protection

Frequently Asked Questions

Q: What information is needed to select the right model?

A: Please provide: application field, measurement range, output signal requirements, liquid type, and power supply specifications.

Q: Are you a manufacturer or trading company?

A: We are an ISO certified manufacturer with OEM/ODM capabilities.

Q: What is your minimum order quantity?

A: Sample orders are acceptable to start our cooperation.

Q: What is your delivery time?

A: Standard delivery is 3-15 working days after payment confirmation.

Q: What payment methods do you accept?

A: We accept T/T, PayPal, and Trade Assurance with 30% deposit for production orders.
