Name: Non-contact Measurement High Precision Radar Liquid Level Gauge for Petrochemical Level Measurement
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KLD800 Series
Price: 1,000.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

Non-contact Measurement High Precision Radar Liquid Level Gauge for Petrochemical Level Measurement

High precision liquid level gauge

Petrochemical liquid level gauge

Non-contact measurement liquid level gauge

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KLD800 Series

Request A Quote

Non-contact Measurement High Precision Radar Liquid Level Gauge for Petrochemical Level Measurement

Product Details

Measuring Range::

0.05m～10/20/30/60/100m

Protection Class:

IP67

Center Frequency::

80GHz

Antenna Material::

PTFE

Process Pressure::

-0.1～2.5MPa

Highlight:

High precision liquid level gauge

Petrochemical liquid level gauge

Non-contact measurement liquid level gauge

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Rs485 Intelligent Ultrasonic Sensor 4 - 20mA Wide Range

Get Best Price

GXRS Series Water Tank Level Indicator Sensor Stainless Steel Material

Get Best Price

KUS550 Ultrasonic Sensor For Distance And Level Measurement with ip68

Get Best Price

RS485 Output Fluid Level Meter Beer Tank Liquid Level Measurement Sensor

Get Best Price

86--17719566736

Contact Now

Product Description

Non-contact Measurement High Precision Radar Liquid Level Gauge for Petrochemical Level Measurement

Product Specifications

Attribute	Value
Measuring range:	0.05m～10/20/30/60/100m
Protection class	IP67
Center frequency:	80GHz
Antenna material:	PTFE
Process pressure:	-0.1～2.5MPa

Product Description

Measurement Principle

The non-contact measurement high precision radar liquid level gauge is specifically designed for petrochemical level measurement applications where accuracy and safety are critical. Using microwave signal technology, it precisely determines liquid levels without direct contact with hazardous or corrosive substances. This advanced radar technology provides extremely accurate measurements (±2mm) for optimal inventory management and process control in harsh industrial environments.

Key Features

Millimeter wave radar with measurement accuracy up to ±2mm and minimum blind zone of 0.05m
Compact antenna design suitable for various working conditions
Multiple lens antenna options with concentrated energy and strong echo signals
Excellent penetration capability for use with adhesion and condensation conditions
Wide dynamic signal range for stable measurement of low dielectric constant media
Multiple measurement modes including fast response radar mode

Model Specifications

KLD801

Medium: Liquid, non-corrosive

Measuring range: 0.05m～10/20/30/60/100m

Process connection: G1½A / 1½NPT thread / flange ≥ DN40

Process temperature: -40～80℃

Process pressure: -0.1～0.3 MPa

KLD802

Medium: Non-corrosive liquid, slightly corrosive liquid

Measuring range: 0.1m~10/20/30/60/100m

Process connection: Flange ≥ DN80

Process temperature: -40～110℃

Process pressure: -0.1～1.6MPa

KLD803

Medium: Strong corrosive liquid, steam, foam

Measuring range: 0.1m～10/20/30/60/100m

Process connection: Flange ≥ DN50

Process temperature: -40～130℃

Process pressure: -0.1～2.5MPa

KLD804

Medium: Non-corrosive liquid, slightly corrosive liquid

Measuring range: 0.1m~10/20/30/60/100m

Process connection: Flange ≥ DN50

Process temperature: -40～130℃

Process pressure: -0.1～1.0MPa

KLD805

Medium: Strong corrosive liquid, steam, foam, high temperature and high pressure

Measuring range: 0.1m~10/20/30/60/100m

Process connection: Flange ≥ DN80

Process temperature: -40～200℃

Process pressure: -0.1～2.5MPa

KLD806

Medium: Solid, storage container, process container, strong dust application

Measuring range: 0.3m~10/20/30/60/100m

Process connection: Flange ≥ DN100

Process temperature: -40～110℃

Process pressure: -0.1～0.3MPa

Production Flow

Packaging & Shipping

Application Cases

Certifications

Company Information

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, ensuring our products meet international standards.

With 10 years of specialization in manufacturing pressure, level and flow measuring instruments, we have become a professional measuring instrument manufacturer and solution provider. Our products are exported to America, Spain, Australia, Chile and 20 other countries, receiving positive feedback from customers worldwide.

Our Services

24-hour response to inquiries
English-speaking technical support
OEM & ODM services available
Distributorship opportunities
Sales area and design protection
Volume discounts available
Paid repair services for non-warranty cases

Frequently Asked Questions

Q: What information is needed to select the appropriate radar liquid level gauge?

A: Please provide: application field, medium, measuring range, output signal, power supply, temperature, and installation method for accurate model selection and quotation.

Q: Are you a manufacturer or trading company?

A: We are an ISO certified manufacturer specializing in level and flow measurement instruments, offering OEM & ODM services.

Q: What is your minimum order quantity?

A: Sample orders are acceptable to initiate our cooperation.

Q: What is your delivery time?

A: Delivery typically takes 3-15 working days after payment confirmation.
