KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring

KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring

Highly Corrosive Liquid Level Gauge

KLD803 radar level gauge

Liquid Level Monitoring radar level gauge

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

CE

Model Number:

KLD803

Contact Us
Request A Quote
Product Details
Medium::
Strong Corrosive Liquid, Steam, Foam
Measuring Range::
0.1m~10/20/30/60/100m
Process Connection::
Flange ≥ DN50
Process Temperature::
-40~130℃
Process Pressure::
-0.1~2.5MPa
Antenna Material::
PTFE
Accuracy:
±2mm (range Below 35m)
Highlight:

Highly Corrosive Liquid Level Gauge

,

KLD803 radar level gauge

,

Liquid Level Monitoring radar level gauge

Payment & Shipping Terms
Minimum Order Quantity
1PCS
Packaging Details
each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
1000 Piece/Pieces per Week negotiable
Product Description
Product Description
The KLD803 radar level gauge is a remarkable instrument specifically engineered for the highly challenging task of monitoring the levels of highly corrosive liquids. It is constructed with highly resistant materials that can endure the harsh and corrosive nature of such substances. By emitting high-frequency radar waves, it precisely measures the distance from the gauge to the liquid surface. These waves bounce back upon hitting the surface, and the gauge calculates the liquid level with great accuracy. It offers a reliable solution in industries like chemical manufacturing, where dealing with highly corrosive acids, alkalis, and other caustic substances is a daily routine. The KLD803 ensures safe and efficient operation by providing accurate and real-time level data, enabling proper control and management of highly corrosive liquid storage and processing.
Parameter

KLD803



KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring 0







Medium: strong corrosive liquid, steam, foam

Measuring range: 0.1m~10/20/30/60/100m

Process connection: flange ≥ DN50

Process temperature: -40~130℃

Process pressure: -0.1~2.5MPa

Antenna size: 34mm lens antenna (according to flange size)

Antenna material: PTFE

Accuracy: ±2mm (range below 35m)

±5mm (range between 35m and 100m)

Protection class: IP67

Center frequency: 80GHz

Launch angle: 3°

Power supply: two-wire /DC24V

four-wire /DC12~24V

four-wire /AC220V

Casing: aluminum/stainless steel

Signal output: two-wire /4...20mA/HART protocol

four-wire 4...20mA/ RS485 Modbus







Apply


KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring 1

KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring 2
KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring 3
Production Flow


KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring 4

Product packaging


KLD803 Radar Level Gauge For Highly Corrosive Liquid Level Monitoring 5
