KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring

KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring

High Temperature Radar Level Gauge

High Pressure Radar Level Gauge

Liquid Level Monitoring Radar Level Gauge

Place of Origin:

china

Brand Name:

KACISE

Certification:

CE

Model Number:

KLD805

Contact Us
Request A Quote
Product Details
Medium:
Strong Corrosive Liquid, Steam, Foam, High Temperature. And High Pressure
Measuring Range:
0.1m~10/20/30/60/100m
Process Connection:
Flange ≥ DN80
Process Temperature:
-40~200℃
Accuracy:
±2mm
Highlight:

High Temperature Radar Level Gauge

,

High Pressure Radar Level Gauge

,

Liquid Level Monitoring Radar Level Gauge

Payment & Shipping Terms
Minimum Order Quantity
1PCS
Packaging Details
each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
1000 Piece/Pieces per Week negotiable
Product Description
Product Description
The KLD805 radar level gauge is a cutting-edge solution for high temperature and high pressure liquid level monitoring. It is built with premium-grade materials and advanced engineering to endure the rigors of such extreme conditions. The gauge functions by emitting highly focused radar beams that can penetrate the high-temperature and high-pressure vapor layers and precisely strike the liquid surface. Upon reflection, the gauge's sensitive receiver captures the signals and, through sophisticated algorithms, calculates the exact liquid level with remarkable accuracy. This device is indispensable in industries like oil refining, chemical synthesis, and power plant operations. It not only provides real-time and dependable level readings but also contributes to enhanced safety and optimized process control, ensuring the seamless and efficient running of systems dealing with high temperature and high pressure liquids.
Parameter

KLD805





KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 0





Medium: strong corrosive liquid, steam, foam,

high temperature. and high pressure

Measuring range: 0.1m~10/20/30/60/100m

Process connection: flange ≥ DN80

Process temperature: -40~200℃

Process pressure: -0.1~2.5MPa

Antenna size: 76mm lens antenna (according to flange size)

Antenna material: PTFE/overall filling

Accuracy: ±2mm

Protection class: IP67

Center frequency: 80GHz

Launch angle: 3°

Power supply: two-wire /DC24V

four-wire /DC12~24V

four-wire /AC220V

Casing: aluminum / plastic / stainless steel

Signal output: two-wire /4...20mA/HART protocol

four-wire 4...20mA/ RS485 Modbus





Apply


KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 1

KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 2
KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 3
Production Flow


KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 4

Product packaging


KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 5

Company Profile


KLD805 Radar Level Gauge For High Temperature And High Pressure Liquid Level Monitoring 6
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
