| Place of Origin: | China (Mainland) |
| Brand Name: | Kacise |
| Certification: | certificate of explosion-proof, CE |
| Model Number: | KS3ARG03D |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 Pieces per Week |
| Bias: | ≤±0.05(゜/s) | Input Voltage: | 5(VDC) |
|---|---|---|---|
| Bias Stability: | ≤0.2(゜/h) | Vibration: | 6.06(g) |
| Electrical Interface: | RS422 | Nonlinearity: | ≤0.02(%FR) |
| Size: | 45×39×20(mm) | Storage Temperature: | -55~+85(°C) |
| High Light: | Solid State Electric Gyro,2000Hz Electronic Gyroscope Sensor,Solid State Electronic Gyroscope Sensor |
||
| Performance parameter | KS3ARG-03D | |
| gyro |
range (deg/s) |
±500 |
| Zero-bias(deg/s) | ≤±0.05(In 500°/s) | |
| Zero-bias stability(deg/h) | ≤0.2 | |
| Zero-bias repeatability(deg/s) | ≤0.02 | |
| nonlinearity(%FR) | ≤0.02 | |
| Mean time between failures(Kh MTBF) | 10 | |
| Interface characteristic | power(V) | DC5 |
| power dissipation(W @5V DC) | ≤1.1 | |
| electrical interface | RS422 | |
| data updating rate(can set) | 2000(Hz@460800) | |
| operating environment | operating temperature(°C) | -40~+80 |
| storage temperature(°C) | -55~+85 | |
| Vibration(g @ 20~2000 Hz) | 6.06 | |
| Shock(g , 0.1 ms, 1/2 Sine) | 5000 | |
| physical property | Size(mm) | 45×39×20 |
| Weight(g) | ≤50 | |
Thank you for choosing our Electronic Gyroscope Sensor. We are committed to providing you with the best technical support and service for your product. Here is the information you need to get the most out of your sensor:
Our user manual contains all the necessary information for setting up and using the Electronic Gyroscope Sensor. It includes detailed instructions for installation, calibration, and troubleshooting. You can find the user manual in the package or download it from our website.
If you encounter any technical issues or have any questions about the sensor, our online technical support team is here to help. You can contact us through email or live chat on our website. Our experienced technicians will provide you with timely and professional assistance.
We offer a one-year warranty for our Electronic Gyroscope Sensor. If you encounter any defects or malfunctions within the warranty period, please contact us for a replacement or repair. Our goal is to ensure that you have a satisfactory experience with our product.
We are committed to continuously improving and upgrading our products. You can stay updated with the latest features and enhancements by subscribing to our newsletter or following us on social media platforms.
We also provide training and consulting services for our Electronic Gyroscope Sensor. Our team of experts can assist you in optimizing the performance of the sensor and integrating it into your specific application.
We hope you find this information useful. If you need any further assistance, please do not hesitate to contact us. We value your feedback and are always striving to improve our products and services.
Thank you again for choosing our Electronic Gyroscope Sensor.
The Electronic Gyroscope Sensor is a delicate and precision instrument that requires careful handling during packaging and shipping to ensure its safe arrival to the customer.
The Electronic Gyroscope Sensor will be packaged in a sturdy and protective box to prevent any damage during transportation. The box will be labeled with the product name and specifications for easy identification.
The sensor will be wrapped in a layer of bubble wrap to provide additional cushioning and protection against any impact. Any sensitive components will be further secured with foam padding to prevent any damage.
For international shipments, the box will also include appropriate customs forms and documentation to ensure a smooth delivery process.
We offer multiple shipping options to accommodate our customers' needs. The Electronic Gyroscope Sensor can be shipped via air, sea, or ground transportation.
We also provide tracking information for all shipments so customers can easily track the status of their order.
Our shipping team takes great care in packaging and handling the Electronic Gyroscope Sensor to ensure its safe and timely delivery to our customers. However, in the rare event of any damage during shipping, we offer a return and exchange policy for our customers' satisfaction.
