| Place of Origin: | China (Mainland) |
| Brand Name: | Kacise |
| Certification: | certificate of explosion-proof, CE |
| Model Number: | KS3ARGA2 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 Pieces per Week |
| Weight: | ≤50(g) | Run-up Time: | ≤5(ms) |
|---|---|---|---|
| Bias Stability: | 12(°/h) | Range: | ±300(°/s) |
| G-value Sensitivity: | <0.02(°/s/g) | Size: | 43×30.5×30.5(mm) |
| Scaling Factor: | 3.3±0.05(mv/°/s) | Temperature Drift: | ≤±0.1(°/s/°C) |
| Offset Voltage: | 1.65±0.02(V) | ||
| High Light: | Analog Output MEMS Gyroscope Sensor,Fast Start MEMS Gyroscope Sensor |
||
| Parameter | KS3ARG-A2 |
| Range(°/s) | ±300(X,Y,Z) |
| Offset voltage(V) | 1.65±0.02 |
| Scaling factor(mv/°/s) | 3.3±0.05 |
| Output voltage(V) | 0.66～2.64 |
| zero-bias stability(°/h) | 12 |
| Temperature drift(°/s/°C) | ≤±0.1 |
| Nonlinearity(%FR) | ≤0.05 |
| Resolution/Threshold(°/s) | ≤0.1 |
| Cross coupling(%) | ≤2 |
| Output noise(°/s√Hz) | ≤0.02 |
| run-up time(ms) | ≤5 |
| Bandwidth(Hz)can customize | ≤100 |
| G-value sensitivity(°/s/g) | ≤0.02 |
| Mean time between failures(MTBF) | 100000hour |
| Oerating Environment | |
| Operating temperature range(°C) | -45～+105 |
| Storage temperature(°C) | -65～+125 |
| Tolerated acceleration(g) | 20000(0.1ms) |
| Size(mm) | 43*30.5*30.5 |
| Weight(g) | ≤50 |
Thank you for choosing our Electronic Gyroscope Sensor. We are committed to providing high-quality technical support and service to ensure the best experience for our customers.
Our team of experts is dedicated to assisting you with any technical issues or questions you may have regarding our Electronic Gyroscope Sensor. Please feel free to contact us through email, phone, or our online support portal.
We also provide detailed user manuals and guides for easy installation and operation of our product. If you encounter any problems during setup, our technical support team will be available to guide you through the process.
In addition to technical support, we also offer a range of services to ensure the smooth functioning of our Electronic Gyroscope Sensor.
Our service team is well-trained and equipped to handle any maintenance or repairs that may be required.
We take pride in the quality of our products and offer a warranty for any defects or malfunctions within the specified period. If you encounter any issues with your Electronic Gyroscope Sensor, please contact our customer service team for assistance.
We appreciate your trust in our product and are committed to providing the best technical support and service. Thank you for choosing our Electronic Gyroscope Sensor.
Our electronic gyroscope sensor is carefully packaged to ensure safe delivery to our customers. The product is first placed in a sturdy cardboard box, which is then wrapped in bubble wrap for extra protection. The box is sealed with packing tape to prevent any damage
during transportation.
Inside the box, the sensor is placed in a plastic bag to further protect it from any potential moisture or dust. The bag is labeled with the product name and specifications for easy identification. Additionally, there is a user manual included to guide customers in using the sensor.
For shipping, we use reliable and reputable courier services to ensure timely and secure delivery. The package is also marked with fragile labels to alert handlers to handle it with care.
We also offer customized packaging and shipping options for bulk orders to meet the specific needs of our customers.
Thank you for choosing our electronic gyroscope sensor. We hope it will exceed your expectations and provide accurate and reliable data for your projects.
