Precision Vibration Accelerometer For Vibration Measurement <1μg Resolution 15g Vibration Peak Sine

Product Description:

The Quartz flexible accelerometer is a precision instrument that consists of a quartz glass flexible support and advanced servo circuit based on the principal of inertia. When subjected to acceleration, the output of the accelerometer is precisely proportional to the input acceleration. Our accelerometer has a current output form of high output impedance, which allows users to choose the sampling resistance according to their requirements without affecting the stability of the system. In terms of technical specifications, the quartz flexible accelerometer offers unmatched accuracy and precision when it comes to measuring acceleration.

Product range

Currently, our quartz flexible accelerometer has evolved into a series of products, with dozens of types ranging from the high-precision μg KSQA07 accelerometer for satellite microgravity measurement, to the low-cost, anti-harsh environment KSQA13 accelerometer. The series is widely used in aerospace, aviation, navigation, ship, vehicle, petroleum, geotechnical engineering and other fields, providing signals for navigation, guidance, control, leveling, monitoring and other systems. As a result, the quartz flexible accelerometer is known to provide reliable and accurate readings, regardless of the application.

Unmatched versatility

Given the versatility and wide range of applications for our quartz flexible accelerometers, the series has become an indispensable tool for anyone looking to measure acceleration accurately. With their superior accuracy and precision, they provide reliable measurement data that is critical for ensuring the success of various navigation, guidance, control, leveling and monitoring systems. As such, our series of quartz flexible accelerometers is trusted by experts in diverse industries, from aerospace to geotechnical engineering.

Features:

• Product Name: Accelerometer Sensor
• Weight: ≤75g
• Storage Temperature: -55~ +80(℃)
• Vibration Peak Sine: 15g
• Threshold: <1μg
• Size: Ø25×29mm
• Analog Devices accelerometers
• Mini accelerometer
• High g accelerometer

Features:

● Excellent index repeatability

● Analog output

● Build-in digital temperature sensor

● Wide load resistance range

● Triangle precision mounting flanges

● Application in the inertial navigation system of the new generation weapon

● Two models are available

Technical Parameters:

Applications:

● Inertial monitoring system

● Inertial navigation system

● Flight control system

● Vibration monitoring

● Oil drilling platforms and geological exploration

● Inertial measurement unit

● Motion monitoring equipment

Support and Services:

The Accelerometer Sensor product offers the following technical support and services:

• Expert technical assistance and troubleshooting for any issues related to the product and its installation
• Product training and documentation to help users fully understand the features and capabilities of the product
• Repair and replacement services for any defective or damaged products
• Customized solutions and consulting services to meet the unique needs of specific applications

Packing and Shipping:

Product Packaging:

• 1 Accelerometer Sensor
• User manual
• Protective packaging

Shipping:

• Ships within 24 hours of order confirmation
• International shipping available at additional cost
• Shipped via trusted courier service
